Experience Innovation and Style with the 40-TRU-VIEW-XL-DEEP 3-Sided Electric Fireplace
The stylish 40-TRU-VIEW-XL-DEEP 3 sided electric fireplace is truly innovative! The stunning flame presentation and unique media options can now be viewed from almost any angle through 3 sides of glass viewing area.
Designed for finishing materials are to be built flush to the lip for a clean face finish. Built-In only. No trim or surround included.The Tru-ViewXL-DEEP series work beautifully as Corner Electric Fireplace.Perfect for any space, inside or out, including bathrooms.
Boasting a depth of 14 1/4”, the 40-TRU-VIEW-XL-DEEP features two flame sets, ambient canopy lighting in 13 colors to illuminate the decorative media like never before and our exclusive FIRE & ICE® flame presentation that allows users to choose from blue, rose, violet, yellow or orange colored flames with just the click of the remote control.
Customize the appearance of the 40-TRU-VIEW-XL-DEEP further by utilizing the included Designer Media Kit which includes a Deluxe 15 piece log set, pebbles, black glass and ICE media. Further media options available for additional purchase.
4 Installation Options:
- all 3 sides of glass visible
- Left side visible
- Right visible
- front only for an extra deep (14 1/4″) fireplace
Ideal Applications
- Residential spaces
- Patios
- Outdoor spaces
- Commercial spaces
- Restaurants
- New construction or renovations
Features
- Available in 40", 50", 60 and 72 sizes.
- Incredible 3 sided glass viewing area.
- All models are rated for either indoor or outdoor use
- State‐of‐the‐art FIRE & ICE ® flame set, with a click of the remote, change the flame from traditional colors such as yellow and orange to more contemporary colors like blue, purple, rose and violet.
- Can produce up to 4800 BTU of heat, enough to heat up to 500 sq feet
- 2 Stage heater
- Hard‐wire ready
- Thermostat hard‐wire ready
- Flame operates with or without heat
- Remote control for flame and heater
- 2 flame sets
This corner fireplace can open left or open right or can have 3 sides open.
Specifications
| 40-TRU-VIEW-XL-DEEP |
| Volts |
120V AC 60Hz |
| Amps |
12.5 |
| Watts |
1500 max |
| Heater |
1500 watts high
750 watts low |
| No Heater |
22 watts |
| Motor Heater |
19 watts |
| Lamps |
LED 22 watts |
| Rotor Motor |
1 at 5 watts |
| Height, Width, Depth |
26 5/8 x 43 1/4 x 14 1/4“ |
| Glass View Opening |
15 5/8 x 39 5/8” |
| Surround Size |
N/A |
| Shipping Size |
31 7/8 x 51 x 16 1/8” |
| Shipping Weight |
121 lbs. Glass Included |
| Plug Location |
Left Side |
| Cord Length |
70 7/8” |
| Approx. Heating Area |
400 sq. ft. |
Included Accessories
The 40-Tru-View-XL-DEEP electric fireplace comes with a choice of a Design Media kit – Driftwood, Birch or Rustic, or ICE media kit and a Remote control for flame and heater.
*Remote control may not be exactly as shown
Amantii Tru-View XL Deep 40" Built-In Three Sided Electric Fireplace Owner's Manual
